ABB AC800PEC Controller

The AC 800PEC provides the optimum solution for high speed control
requirements of power converters.
The AC 800PEC is a high-end controller belonging to ABB’s 800xA family.
It is configured and programmed with Control Builder M and MATLAB®/
Simulink® with Real-Time Workshop®. The controller combines a very
powerful CPU and large Field-Programmable Gate Array, which suits AC
800PEC to control demanding power electronics systems.
The AC 800PEC is mounted on a DIN rail.
Ethernet is used as preferred medium for configuration and communication to upper control. The AC 800PEC interfaces with ABBs I/O systems
via the optical S800 Modulebus and with ABB’s communication modules
via Communication Expansion Bus (CEX). It also supports 3rd party
AnyBus-S® fieldbus modules.
The AC 800PEC I/O modules are connected via high-speed point-to-point
connections. AC 800PEC supports up to 36 bi-directional fiber optic
power-links.

The AC 800PEC control system is a set of modules. The modules are
arranged according to the required I/O configuration and process needs.
the AC 800PEC arrangement consists of:
• AC 800PEC controller module (1)
• AC 800PEC Combi IO modules (2)
• AC 800PEC INT interface modules (3)
• S800 I/O modules (4)
• CEX-bus extension module (5)
• AC 800PEC PEBB Interface boards
• AC 800PEC Measurement Interface

Types:
PPC905AE101
PPC907
PPC907BE
PPC907BE101
PPD113B01-10-150000
PPD113B03-26-100110
PPD115A102
PPD512
PPD512A10-454000
3BHE040375R103E
PPD539A102
3BHE039770R0102
PPEO91A101

PV D164
UA D149
PP D113
DD C779
GD D160
GD D165
UA D144
S800I/O
CI85x
TB 820
TB 830
TB 831
